Specifications:
n Display: Large LCD characters display
n Measurement principle: Electrical resistance
n Range: Wood: 0~99.9%
n Resolution: 0.1%
n Accuracy: ±0.5%
n Electrode length: 10mm(0.4″)
n Electrode pins: Integrated
n Auto Power OFF: After approx.15 minutes
n Power Supply: One 9V battery
n Meter housing: ABS plastic
n Operating Temperature: 0 to 40 (32 to 104)
n Dimensions: 145 X 67 X 32mm (5.7″ x 2.6″ x 1.3″)
n Weight: 130g (4. 59oz)
Wood Species Group Table:
| Wood Group | Wood Species |
|
A |
Teak, Walnut, Afrormosia, Rubber Tree, Imbuia, Kokrodua, Niove Bidinkala, Cork |
|
B |
Keruing, White Poplar, Beech, Cedar, Tola |
|
C |
Lauan, Ash, Elm, Fir, Maple, Padauk, Oak, Cherry |
|
D |
Basswood, Larch, Pine, Birch |
